| 型号 | 阻值(Ω) | 额定功率 | 温度系数值(ppm/℃) | 阻值精度 | 尺寸(inch) |
| RLC-12KR900FT | 0.900Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR750FT | 0.750Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR680FT | 0.680Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR620FT | 0.620Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR560FT | 0.560Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR510FT | 0.510Ω | 1W | ±100 | ±1% | 2512 |
| RLP-12KR500FT | 0.500Ω | 2W | ±100 | ±1% | 2512 |
| RLC-12KR500FT | 0.500Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR470FT | 0.470Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR430FT | 0.430Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR390FT | 0.390Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR360FT | 0.360Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR330FT | 0.330Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR300FT | 0.300Ω | 1W | ±100 | ±1% | 2512 |
| RLP-12KR300FT | 0.300Ω | 2W | ±100 | ±1% | 2512 |
| RLP-12KR250FT | 0.250Ω | 2W | ±100 | ±1% | 2512 |
| RLC-12KR250FT | 0.250Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR240FT | 0.240Ω | 1W | ±100 | ±1% | 2512 |
| RLP-12KR220FT | 0.220Ω | 2W | ±100 | ±1% | 2512 |
| RLC-12KR220FT | 0.220Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR200FT | 0.200Ω | 1W | ±100 | ±1% | 2512 |
| RLP-12KR200FT | 0.200Ω | 2W | ±100 | ±1% | 2512 |
| RLC-12KR150FT | 0.150Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR120FT | 0.120Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR100FT | 0.100Ω | 1W | ±100 | ±1% | 2512 |
| RLP-12KR100FT | 0.100Ω | 2W | ±100 | ±1% | 2512 |
| RLC-12KR075FT | 0.075Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR060FT | 0.060Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12KR050FT | 0.050Ω | 1W | ±100 | ±1% | 2512 |
| RLC-12AR010FT | 0.010Ω | 1W | ±600 | ±1% | 2512 |
| RLP-10KR750FT | 0.750Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10KR680FT | 0.680Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10KR620FT | 0.620Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10KR510FT | 0.510Ω | 1W | ±100 | ±1% | 2010 |
| RLS-10KR500FT | 0.500Ω | 3/4W | ±100 | ±1% | 2010 |
| RLP-10KR470FT | 0.470Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10KR430FT | 0.430Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10KR390FT | 0.390Ω | 1W | ±100 | ±1% | 2010 |
| RLS-10KR330FT | 0.330Ω | 3/4W | ±100 | ±1% | 2010 |
| RLP-10KR330FT | 0.330Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10KR300FT | 0.300Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10KR200FT | 0.200Ω | 1W | ±100 | ±1% | 2010 |
| RLS-10KR200FT | 0.200Ω | 3/4W | ±100 | ±1% | 2010 |
| RLP-10KR100FT | 0.100Ω | 1W | ±100 | ±1% | 2010 |
| RLS-10KR100FT | 0.100Ω | 3/4W | ±100 | ±1% | 2010 |
| RLS-10KR080FT | 0.080Ω | 3/4W | ±100 | ±1% | 2010 |
| RLP-10KR050FT | 0.050Ω | 1W | ±100 | ±1% | 2010 |
| RLP-10AR010FT | 0.010Ω | 1W | ±600 | ±1% | 2010 |
| RLP-06KR976FT | 0.976Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR910FT | 0.910Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR910FT | 0.910Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR900FT | 0.900Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR820FT | 0.820Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR820FT | 0.820Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR800FT | 0.800Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR750FT | 0.750Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR680FT | 0.680Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR680FT | 0.680Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR640FT | 0.640Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR620FT | 0.620Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR620FT | 0.620Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR590FT | 0.590Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR560FT | 0.560Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR560FT | 0.560Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR510FT | 0.510Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR510FT | 0.510Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR500FT | 0.500Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR500FT | 0.500Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR475FT | 0.475Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR470FT | 0.470Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR470FT | 0.470Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR450FT | 0.450Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR430FT | 0.430Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR392FT | 0.392Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR390FT | 0.390Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR360FT | 0.360Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR360FT | 0.360Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06WR360FT | 0.360Ω | 1/4W | ±200 | ±1% | 1206 |
| RLS-06KR330JT | 0.330Ω | 1/4W | ±100 | ±5% | 1206 |
| RLP-06KR330FT | 0.330Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR330FT | 0.330Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR300FT | 0.300Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR300FT | 0.300Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR280FT | 0.280Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR260FT | 0.260Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR250FT | 0.250Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR240FT | 0.240Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR240FT | 0.240Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR220FT | 0.220Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR200FT | 0.200Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR200FT | 0.200Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR180FT | 0.180Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR180FT | 0.180Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR160FT | 0.160Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR150FT | 0.150Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR150FT | 0.150Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR140FT | 0.140Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR130FT | 0.130Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR130FT | 0.130Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR120FT | 0.120Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR120FT | 0.120Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR110FT | 0.110Ω | 1/4W | ±100 | ±1% | 1206 |
| RLS-06KR100JT | 0.100Ω | 1/4W | ±100 | ±5% | 1206 |
| RLP-06KR100JT | 0.100Ω | 1/2W | ±100 | ±5% | 1206 |
| RLS-06KR100FT | 0.100Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR100FT | 0.100Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06KR091FT | 0.091Ω | 1/2W | ±100 | ±1% | 1206 |
| RLS-06KR082FT | 0.082Ω | 1/4W | ±100 | ±1% | 1206 |
| RLP-06KR075FT | 0.075Ω | 1/2W | ±100 | ±1% | 1206 |
| RLP-06JR056FT | 0.056Ω | 1/2W | ±150 | ±1% | 1206 |
| RLP-06JR051FT | 0.051Ω | 1/2W | ±150 | ±1% | 1206 |
| RLS-06JR050FT | 0.050Ω | 1/4W | ±150 | ±1% | 1206 |
| RLP-06UR047FT | 0.047Ω | 1/2W | ±400 | ±1% | 1206 |
| RLP-06UR045FT | 0.045Ω | 1/2W | ±400 | ±1% | 1206 |
| RLP-06UR036FT | 0.036Ω | 1/2W | ±400 | ±1% | 1206 |
| RLP-06UR027FT | 0.027Ω | 1/2W | ±400 | ±1% | 1206 |
| RLS-06AR012JT | 0.012Ω | 1/4W | ±600 | ±5% | 1206 |
| RLS-06AR010FT | 0.010Ω | 1/4W | ±600 | ±1% | 1206 |
| RLP-06AR010FT | 0.010Ω | 1/2W | ±600 | ±1% | 1206 |
| RLP-05KR910FT | 0.910Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR900FT | 0.900Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR820FT | 0.820Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR750FT | 0.750Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR680FT | 0.680Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR680FT | 0.680Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR560FT | 0.560Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR510FT | 0.510Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR500FT | 0.500Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR500FT | 0.500Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR470FT | 0.470Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR470FT | 0.470Ω | 1/4W | ±100 | ±1% | 0805 |
| RLP-05KR430FT | 0.430Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR430FT | 0.430Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR390FT | 0.390Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR390FT | 0.390Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR360FT | 0.360Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR330FT | 0.330Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR300FT | 0.300Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR270FT | 0.270Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR240FT | 0.240Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR220FT | 0.220Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR220FT | 0.220Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR210FT | 0.210Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR200FT | 0.200Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR200FT | 0.200Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR180FT | 0.180Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR180FT | 0.180Ω | 1/4W | ±100 | ±1% | 0805 |
| RLP-05KR165FT | 0.165Ω | 1/4W | ±100 | ±1% | 0805 |
| RLP-05KR160FT | 0.160Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR150FT | 0.150Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR150FT | 0.150Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR130FT | 0.130Ω | 1/8W | ±100 | ±1% | 0805 |
| RLS-05KR120FT | 0.120Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR120FT | 0.120Ω | 1/4W | ±100 | ±1% | 0805 |
| RLP-05KR100FT | 0.100Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05KR100FT | 0.100Ω | 1/8W | ±100 | ±1% | 0805 |
| RLP-05KR091FT | 0.091Ω | 1/4W | ±100 | ±1% | 0805 |
| RLP-05KR075FT | 0.075Ω | 1/4W | ±100 | ±1% | 0805 |
| RLP-05KR068FT | 0.068Ω | 1/4W | ±100 | ±1% | 0805 |
| RLS-05JR056FT | 0.056Ω | 1/8W | ±150 | ±1% | 0805 |
| RLP-05JR056FT | 0.056Ω | 1/4W | ±150 | ±1% | 0805 |
| RLS-05JR051FT | 0.051Ω | 1/8W | ±150 | ±1% | 0805 |
| RLP-05JR051FT | 0.051Ω | 1/4W | ±150 | ±1% | 0805 |
| RLP-05JR050FT | 0.050Ω | 1/4W | ±150 | ±1% | 0805 |
| RLP-05UR040FT | 0.040Ω | 1/4W | ±400 | ±1% | 0805 |
| RLP-05UR033FT | 0.033Ω | 1/4W | ±400 | ±1% | 0805 |
| RLP-05AR020FT | 0.020Ω | 1/4W | ±600 | ±1% | 0805 |
| RLS-05AR020FT | 0.020Ω | 1/8W | ±600 | ±1% | 0805 |
| RLP-05ZR010FT | 0.010Ω | 1/4W | ±1200 | ±1% | 0805 |
| RLS-05ZR010FT | 0.010Ω | 1/8W | ±1200 | ±1% | 0805 |
| RLS-03WR680FT | 0.680Ω | 1/10W | ±200 | ±1% | 0603 |
| RLP-03WR600FT | 0.600Ω | 1/5W | ±200 | ±1% | 0603 |
| RLS-03WR560FT | 0.560Ω | 1/10W | ±200 | ±1% | 0603 |
| RLP-03WR510FT | 0.510Ω | 1/5W | ±200 | ±1% | 0603 |
| RLS-03WR500FT | 0.500Ω | 1/10W | ±200 | ±1% | 0603 |
| RLS-03WR470FT | 0.470Ω | 1/10W | ±200 | ±1% | 0603 |
| RLP-03WR430FT | 0.430Ω | 1/5W | ±200 | ±1% | 0603 |
| RLS-03WR400FT | 0.400Ω | 1/10W | ±200 | ±1% | 0603 |
| RLS-03WR390FT | 0.390Ω | 1/10W | ±200 | ±1% | 0603 |
| RLP-03WR360FT | 0.360Ω | 1/5W | ±200 | ±1% | 0603 |
| RLS-03WR360FT | 0.360Ω | 1/10W | ±200 | ±1% | 0603 |
| RLP-03WR220FT | 0.220Ω | 1/5W | ±200 | ±1% | 0603 |
| RLP-03WR200FT | 0.200Ω | 1/5W | ±200 | ±1% | 0603 |
| RLS-03WR200FT | 0.200Ω | 1/10W | ±200 | ±1% | 0603 |
| RLP-03WR180FT | 0.180Ω | 1/5W | ±200 | ±1% | 0603 |
| RLS-03WR150FT | 0.150Ω | 1/10W | ±200 | ±1% | 0603 |
| RLS-03WR100FT | 0.100Ω | 1/10W | ±200 | ±1% | 0603 |
| RLP-03WR100FT | 0.100Ω | 1/5W | ±200 | ±1% | 0603 |
| RLS-03BR060FT | 0.060Ω | 1/10W | ±300 | ±1% | 0603 |
| RLP-03BR051FT | 0.051Ω | 1/5W | ±300 | ±1% | 0603 |
| RLS-03BR050FT | 0.050Ω | 1/10W | ±300 | ±1% | 0603 |
| RLC-02BR150FT | 0.150Ω | 1/16W | ±300 | ±1% | 0402 |
